CS Hand Draw Curtain Track Set

CS-HD-4-WH

Forest

$ 80.30

Quantity

The wave system is now available on most of our of our tracks. Select wavefold carrier for this option. To learn more, view on our wavefold collection page. Ball bearing carriers are typically used with pleated draperies or curtains with pin hooks

Forest CS complete assembled hand draw track set with ball bearing carriers for pleated draperies or swivel slides or swivel slides w/ attached hook for grommet curtains. Can also be used with our wave fold panels (select swivel slides for wavefold). Can easily be cut to size with a hack saw, or if you leave a dimension(s), we will cut it to size. Available in wall or ceiling mount.

Heavy duty aluminum track, powder coated white, black or gray. 3/4" high, 3/4" deep, reversible track. This track has 90 degree and 45 degree bends available. See the CS parts page. Be sure to order splices to join the bend with the straight track sets.

Track is rated at 6 lbs per foot; for example, a 10 ft. track will hold a maximum of 60 lbs.

Each set includes track, end caps, wall brackets or ceiling clips, splices and slides (3 1/2 per foot for ball bearing carriers, swivel slide and swivel slides with attached hook).

If Wavefold carriers are selected, you will receive the following quantities. This will often be more than required. Cut the string to remove the excess.

(48"-24)(60"-28)(72"-40)(84"-48)(95"-48)(120"-60)(144"-72)(168"-96)(180"-96)(204"-120)(228"-120)(252"-144)(336"-168)

Pin setting using ball bearing carriers for pleated draperies should be 1 1/2"

Batons can be added and are available to purchase separately.

Great tracks of Forest Group

I’m a big fan of Forest Group curtain tracks — they’re always high quality, and the well-designed mounting system makes installation quick and easy. I’ve worked with their products in Europe and was thrilled to find them available in the United States as well.

The ability to build your own track setup is a huge plus and significantly reduces the overall cost. I was honestly shocked by the prices of similar tracks from other brands across various websites — they seem heavily overpriced compared to what I’ve seen in Europe.

Curtain Rod Connection offers the most reasonable pricing I’ve found, and their product listings are extremely well-organized. Each part is clearly labeled with the track series it’s compatible with, which makes it easy to select exactly what I need — from the number of carriers to the amount of mounting brackets, based on the weight of my curtains.

I was also pleasantly surprised to find that they offer end stops (a very useful feature during curtain installation), as well as Wavefold carriers. My only regret is that they currently offer only one spacing option — 2 3/8" (60 mm). I would love to see the 3 5/32" (80 mm) option available as well.

Just perfect

Needed to replace our track for some heavy drapes. These were the only ones I could find that would not need me to alter the drapes. Very sturdy, size was perfect

Works as expected

Really happy with our track purchase. The shipping was super fast and the installation of the track was pretty easy. Our hardest step is hemming the curtains!

Very nice and quick delivery!

Surprisingly good

Usually I find putting up curtain rods as tedious, but these are different. Easy to trim to size and the brackets are movable so they are easier than usual to move, also love the hex screws, no stripping with these. I have already ordered another set, so really love these.
